Product Description
Want a showerhead and a hand shower in the same shower? The Symmons Origins shower system trim, model 9605-PLR-1.5-TRM, is the visible part of the system, in Polished Chrome.
This listing is the trim only. The valves in the wall are sold separately. Symmons names the Temptrol valve body 262BODY and the dual outlet diverter valve body 2DIVBODYSRT for this trim. The Temptrol valve also comes with the Rapid Install mounting bracket as model 262BRBODY. A tub spout is not included.
The trim has a single mode round showerhead with a shower arm, a single mode hand shower on a 60 in. flexible metal hose and a 36 in. slide bar for the hand shower. It comes with 2 lever handles and 2 escutcheons, and it has a separate two function diverter. The valve cover plate has hot and cold indicators. The showerhead flows at 1.5 gallons per minute (5.7 L/min).
Features
- Trim only: Temptrol valve body 262BODY (or 262BRBODY) and diverter valve body 2DIVBODYSRT are sold separately
- Single mode round showerhead with full spray, with shower arm
- Single mode hand shower with a 60 in. flexible metal hose
- 36 in. slide bar for the hand shower
- 2 lever handles and 2 escutcheons
- Separate two function diverter
- 1.5 GPM (5.7 L/min) flow rate
- Rubber showerhead nozzles
- Wall connection
- Brass, zinc, stainless steel and plastic construction
What's Included
- Showerhead
- Shower arm
- Hand shower
- 60 in. flexible metal hose
- 36 in. slide bar
- 2 escutcheons
- 2 handles
Specifications
| Model | 9605-PLR-1.5-TRM |
| UPC | 671256545548 |
| Brand | Symmons |
| Collection | Origins |
| Finish | Polished Chrome |
| Flow Rate | 1.5 GPM (5.7 L/min) |
| Showerhead | Single mode, round, full spray |
| Hand Shower | Single mode |
| Hose | 60 in. flexible metal |
| Slide Bar | 36 in. |
| Handles | 2 lever handles |
| Construction | Brass, zinc, stainless steel and plastic |
| Valve Body Required | Symmons Temptrol 262BODY or 262BRBODY (sold separately) |
| Diverter Valve Required | Symmons 2DIVBODYSRT (sold separately) |
| Shower Valve Hole Size | Min. 3 in., max. 4 in. diameter |
| Diverter Valve Hole Size | Min. 3 in., max. 3-1/4 in. diameter |
| Rough-In | 2-3/8 in., plus or minus 1/2 in. |
| Weight | 8.64 lb |
| Warranty | Symmons states: "limited lifetime warranty" |
